1" Diameter, Horizontal Keyed Shaft
Muffler Included
90 Day Limited Warranty
| ENGINE TYPE | TWIN CYLINDER 4-STROKE OHV |
| BORE X STROKE | 78 x 70 mm |
| DISPLACEMENT | 669cc |
| COMPRESSION RATIO | 8.5:1 |
| NET POWER | 15.5 kW / 3600 RPM |
| NET TORQUE | 45 N.m / 2500 RPM |
| PTO SHAFT ROTATION | COUNTERCLOCKWISE |
| IGNITION SYSTEM | TRANSISTORIZED MAGNETO IGNITION |
| STARTING SYSTEM | ELECTRIC START |
| CARBURETOR | FLAT SUCTION VALVE CARBURETOR |
| LUBRICATION SYSTEM | FORCED SPLASH |
| GOVERNOR SYSTEM | CENTRIFUGAL MECHANICAL |
| AIR CLEANER | DUAL ELEMENTS (PAPER OR FOAM) |
| OIL CAPACITY | 1.69 QTS |
| FUEL TANK CAPACITY | N/A |
| DIMENSIONS (LxWxH) | 21.6" x 18.1" x 13.6" |
| NET WEIGHT | 99.2lbs |
| FUEL CONSUMPTION | < 370 G/KW H |
- Product Manual:
- Download
