1" Diameter, Horizontal Keyed Shaft
90 Day Limited Warranty
| ENGINE TYPE | SINGLE CYLINDER 4-STROKE OHV |
| BORE X STROKE | 70 x 55 mm |
| DISPLACEMENT | 301cc |
| COMPRESSION RATIO | 9.0:1 |
| NET POWER | 7 kW / 3600 RPM |
| NET TORQUE | 21 N.m / 2500 RPM |
| PTO SHAFT ROTATION | COUNTERCLOCKWISE |
| IGNITION SYSTEM | TRANSISTORIZED MAGNETO IGNITION |
| STARTING SYSTEM | RECOIL / ELECTRIC START |
| CARBURETOR | FLAT SUCTION VALVE CARBURETOR |
| LUBRICATION SYSTEM | FORCED SPLASH |
| GOVERNOR SYSTEM | CENTRIFUGAL MECHANICAL |
| AIR CLEANER | DUAL ELEMENTS (PAPER OR FOAM) |
| OIL CAPACITY | 1.16 QTS |
| FUEL TANK CAPACITY | 5.7 QTS |
| DIMENSIONS (LxWxH) | 16.5" x 15.5" x 16.9" |
| NET WEIGHT | 57 lbs |
| FUEL CONSUMPTION | < 374 G/KW H |
